CPU Support
Build in AMD Socket sTRX4 for 3rd Gen AMD Ryzen™ Threadripper™ Series Desktop Processors
* Refer to www.asus.com for CPU support list
Memory Support
AMD Ryzen™ Threadripper™ Processors
8 x DIMM, Max. 256GB, DDR4 4733(O.C)/4600(O.C)/4400(O.C)/4333(O.C.)/4266(O.C.)/4133(O.C.)/3800(O.C.)/3733(O.C.)/3400(O.C.)/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory
Quad Channel Memory Architecture
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Audio
ROG SupremeFX 8-Channel High Definition Audio CODEC S1220
– Impedance sense for front and rear headphone outputs
– Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
– High quality 120 dB SNR stereo playback output 108 dB SNR recording input
– ESS® ESS9018Q2C
Audio Feature :
– SupremeFX Shielding™ Technology
– Sonic Studio III + Sonic Studio Virtual Mixer
– DTS® Sound Unbound
– LED-illuminated design – Brighten up your build with the gorgeous illuminated audio trace path.
– Sonic Radar III
Expansion Slots
3rd Gen AMD Ryzen™ Threadripper™ Series Desktop processors
4 x PCIe 4.0 (x16, x16/x16, x16/x8/x16, x16/x8/x16/x8)
Storage
3rd Gen AMD Ryzen™ Threadripper™ Series Desktop processors :
1 x ROG DIMM.2 Module supports 2 M.2 Socket 3 , with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)
2 x M.2 Socket 3, with M Key, type 2242/2260/2280 (PCIe 4.0 x4 mode)*1
3rd Gen AMD Ryzen™ Threadripper™ Series Desktop processors :
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 (PCIe 4.0 x4/x2 mode)*2
Support Raid 0, 1, 10
AMD TRX40 chipset :
4 x SATA 6Gb/s port(s),
ASMedia® SATA 6Gb/s controller :
4 x SATA 6Gb/s port(s),
Back Panel Connectors
1 x LAN (RJ45) port(s)
1 x USB 3.2 Gen 2×2 (up to 20Gbps) ports (Type-C)
4 x USB 3.2 Gen 1 blue
5 x USB 3.2 Gen 2 (red) (3 x Type-A+1 x Type-C)
1 x Optical S/PDIF out
1 x Clear CMOS button(s)
1 x USB BIOS FlashBack™ Button(s)
5 x LED-illuminated audio jacks
1 x Aquantia AQC-107 10G LAN port
ROG Zenith II Extreme Alpha ราคา 27,300 บาท
***ราคาอาจจะมีการเปลี่ยนแปลง***
